SMD LED Module 24V 2835 Chip for Commercial Interiors
Product Details
| Product Name | LED Module | Led Chip | SMD2835 |
|---|---|---|---|
| Warranty | 5 Years/ 50000 Hours | Led Chain | 50pcs Chain |
| Led Color | White 2700k-9000k | Brand Logo | Free Cost Logo |
| Module Size | 32.5*18*9.5mm | Application | Backlit Logos |
| Highlight | SMD LED Module,24V 2835 Chip Module,LED Module for Commercial Interior |
||
Product Description
SMD LED Module 24V 2835 Chip for Commercial Interiors
This high-performance LED module provides even backlighting suitable for medium and large-sized advertising light boxes and brand signage.
Well-designed light distribution eliminates central bright spots and creates soft, consistent illumination on acrylic panels.
Uniform standard size facilitates regular arrangement and improves production efficiency for sign factories.
Product Parameters
| Model No. | LED | Color | CCT (K) | Voltage | Power | LM | Effect (LM/W) | Angle | ||||
| Peime1-MFR061 | SMD2835 | White | 2700~9000K | 12V/24V | 0.36W | 64.8 | 180 | 175° | ||||
| Other Colors | ||||||||||||
| Connection Qty | Shell color | Drive Method | Weight (g/50pcs) | Warranty | W T(℃) | ST(℃) | IP Level | |||||
| 50pcs | White | Constant Voltage | 500 | 5Years Or 50000H | -25-+60 | -25+80 | IP67 | |||||
Product Features
High Brightness Output: Offers sufficient luminous intensity to guarantee clear display under strong ambient light.
Stable Circuit Structure: Effectively reduces failure risks caused by unstable current fluctuation.
Multiple Waterproof Grades: Optional IP ratings satisfy indoor dry space and outdoor exposed installation scenarios.
Led Module Applications
Pharmacy Store Signage
Mobile Phone Shop Logos
Restaurant Menu Light Boxes
FAQ
Q: What wire gauge should be matched for LED module wiring?
A: Wire specification depends on total load power and transmission distance, thicker cables are required for long-distance power supply.
Q: Is it normal for LED modules to generate slight heat when working?
A: Mild heat generation belongs to normal working state; abnormal overheating indicates improper matching or installation issues.
Q: Can I cut the connecting wires of modules on site?
A: Wire shortening is allowed, but proper insulation treatment must be done to avoid short circuit risk.
