Wide Coverage Illumination Module 175° Lens for Backlit Panels
Product Details
| Product Name | LED Module | Led Chip | SMD2835 |
|---|---|---|---|
| Warranty | 5 Years/ 50000 Hours | Led Chain | 50pcs Chain |
| Led Color | White 2700k-9000k | Brand Logo | Free Cost Logo |
| Module Size | 32.5*18*9.5mm | Application | Backlit Logos |
| Highlight | Wide Coverage Illumination Module,175 Degree Lens LED Module,Backlit Panel LED Module |
||
Product Description
Wide Coverage Illumination Module 175° Lens for Backlit Panels
Developed to meet high-standard commercial signage demands, this LED module offers reliable even lighting for backlit letters and advertising panels.
Reasonable light angle layout effectively weakens hotspot phenomenon and delivers delicate display effects.
Modular splicing design freely matches signage of different sizes and irregular shapes.
Product Parameters
| Model No. | LED | Color | CCT (K) | Voltage | Power | LM | Effect (LM/W) | Angle | ||||
| Peime1-MFR061 | SMD2835 | White | 2700~9000K | 12V/24V | 0.36W | 64.8 | 180 | 175° | ||||
| Other Colors | ||||||||||||
| Connection Qty | Shell color | Drive Method | Weight (g/50pcs) | Warranty | W T(℃) | ST(℃) | IP Level | |||||
| 50pcs | White | Constant Voltage | 500 | 5Years Or 50000H | -25-+60 | -25+80 | IP67 | |||||
Product Features
Reliable Constant Current Driving: Ensures stable brightness and slows down luminous decay during long-term operation.
Compact Slim Body: Fits shallow cabinet signs with limited internal installation space.
Convenient Field Maintenance: Single module can be replaced separately without dismantling the whole lighting system.
Led Module Applications
Bookstore Illuminated Signs
Pet Shop Storefront Logos
Bar Interior Light Displays
FAQ
Q: How to reduce voltage drop during construction?
A: Use thicker wire gauge, adopt multi-point power supply and control single group wiring distance.
Q: Are samples available for quality checking?
A: Sample orders are welcome for performance and lighting effect evaluation.
Q: Can waterproof modules be used indoors as well?
A: Yes, waterproof modules can be applied indoors while non-waterproof types cannot be exposed to moisture.
