12V RGBW Backlighting Modules IP68 165° for Letter Lighting
Product Details
| Product Name | RGBW Led Module | Led Chip | SMD5050 |
|---|---|---|---|
| Warranty | 5 Years/ 50000 Hours | Led Chain | 20pcs Chain |
| Led Color | RGBW | Brand Logo | Free Cost Logo |
| Module Size | 83*18*9.8mm | Application | Color Changing Led Letters. |
| Highlight | 12V RGBW Backlight Module,IP68 165 Degree LED Module,Letter Lighting LED Module |
||
Product Description
12V RGBW Backlighting Modules IP68 165° for Letter Lighting
- RGBW Letter Module combines RGB color effects with dedicated white light output for flexible lighting designs.
- 0.96W 24V structure provides stable operation for illuminated letter projects.
- IP68 protection and 165° beam angle help achieve reliable performance with wide light distribution.
Product Parameters
| Model No. | LED | Color | W/CCT (K) | Voltage | Power | LM | Effect (LM/W) | Angle | ||||
| SN-MAD121 | SMD5050 | RGBW | 2700~9000K | 12V/24V | 0.96W | 30 | 120 | 165° | ||||
| Other Colors | ||||||||||||
| Connection Qty | Shell color | Drive Method | Weight (g/20pcs) | Warranty | WT(℃) | ST(℃) | IP Level | |||||
| 20pcs | White | Constant Voltage | 375 | 5Years Or 50000H | -25-+60 | -25+80 | IP68 | |||||
Product Features
• RGBW Color Mixing Design: Supports colorful lighting effects together with dedicated white illumination for more flexible visual designs.
• 24V Stable Operation: Suitable for lighting systems requiring reliable voltage performance and longer connection layouts.
• IP68 Waterproof Protection: Provides strong protection against dust and water for demanding installation environments.
Led Module Applications
- Channel letter lighting
- Illuminated logo projects
- Color-changing signage
FAQ
Q: What is the difference between RGB and RGBW modules?
A: RGBW modules add a dedicated white LED channel, allowing both colorful effects and pure white lighting options.
Q: How does the 165° beam angle affect the lighting result?
A: The wide beam design helps spread light more evenly and reduces uneven brightness in letter structures.
