AC LED Backlight Module 170 Degrees IP67 220V for Large Area Lighting
Product Details
| Product Name | LED Module | Led Chip | SMD2835 |
|---|---|---|---|
| Warranty | 5 Years/ 50000 Hours | Led Chain | 20pcs Chain |
| Led Color | 2700k-9000k. Other Colors. | Brand Logo | Free Cost Logo |
| Module Size | 42*42*10mm | Application | Brand Logos |
| Highlight | 220VAC LED Module 1.8W,185LM 170 Degree Sign Module,220V LED Sign Lighting Modules |
||
Product Description
AC LED Backlight Module 170 Degrees IP67 220V for Large Area Lighting
• High voltage LED module supports AC110V and AC220V direct input, simplifying installation for sign lighting projects.
• Provides stable brightness output and uniform illumination for advertising signs and commercial applications.
• Designed for channel letters, light boxes, and large-scale signage projects requiring reliable performance.
Product Parameters
| Model No. | LED | Color | CCT (K) | Voltage | Power | LM | Effect (LM/W) | Angle | ||||
| AC-TOP-HFR094 | SMD2835 | White | 2700~9000K | 110V/220V | 1.8W | 185 | 103 | 170° | ||||
| Other Colors | ||||||||||||
| Connection Qty | Shell color | Drive Method | Weight (g/20pcs) | Warranty | W T(℃) | ST(℃) | IP Level | |||||
| 20pcs | White | Constant Voltage | 440 | 5Years Or 50000H | -25-+60 | -25+80 | IP67 | |||||
Product Features
• Direct AC voltage operation reduces the need for additional power conversion equipment.
• High efficiency LED design delivers bright output with lower energy consumption.
• Compact structure allows flexible installation in different sign applications.
Led Module Applications
• Channel letter signs and illuminated letters
• Advertising boards and commercial signage
• Light box and backlighting projects
FAQ
Q: Can this high voltage LED module work with 110V and 220V power systems?
A: Yes, different models are available for AC110V or AC220V input requirements.
Q: Does this module need an external transformer?
A: No, the high voltage version is designed for direct AC operation.
Q: Where can this LED module be used?
A: It is suitable for signs, channel letters, advertising lighting, and commercial projects.
